G80/G100
Ruilida
Sheep horn hook
Purpose
Designed for the ends of slings in rapid assembly applications.
The grab hook is precision-forged from high-quality alloy steel for superior durability.
The connection point at the hook tip is engineered to be compatible exclusively with chains of the same model.
Green's engineering experts have also incorporated specialized friction edges on the hook body, utilizing a unique structural design to ensure safety.
It offers simple installation and easy disassembly during operation, with a strength grade of Class 8.
| Serial number | Diameter of matching round link chain | Main dimensions | Weight | Ultinate working load | ||
| D | E | R | ||||
| (mm) | (mm) | (mm) | (mm) | (KG) | (t) | |
| 01 | 7 | 9 | 36 | 95 | 0.45 | 1.5 |
| 02 | 10 | 11.5 | 45 | 120 | 1 | 3.2 |
| 03 | 13 | 15 | 54 | 144 | 2 | 5.4 |
| 04 | 16 | 19 | 60 | 167 | 3.6 | 8.2 |
